XA65 Overview
Shoot, record, document, stream.
Shoot high quality 4K UHD video with the compact XA65. The camera delivers outstanding oversampled HD, advanced autofocus, a Canon 20x optical zoom lens, HD livestreaming with UVC1 via a USB-C connection to a PC or Mac and can capture footage for recording or sharing later in either XF-AVC or MP4 formats.
Compact professional 4K UHD camcorder
Capture stunning 4K UHD and Full HD images thanks to a 4K 1/2.3" type CMOS sensor and DIGIC DV6 image processor. Oversampled HD delivers Full HD images from the 4K sensor.
On-Screen Display (OSD) “Time Stamp” Recording
New to XA-Series cameras, the OSD recording embeds date, time, timecode, and other data into your original camera files effectively “time stamping” the information into each frame of video, a requirement for legal and law enforcement videographers.
UVC Livestreaming
Stream HD video directly from the camera via UVC 1 to a PC or Mac computer.
Professional audio controls
Two XLR terminals on a detachable handle plus 4-channel linear PCM bring a suite of pro audio options.
4K 20x optical zoom lens
The Canon lens covers a 29.3mm wide angle (35mm equivalent) with a powerful 612mm reach. Digital zoom boosts the 20x optical zoom to 800x magnification. To minimize camera shake, the camera provides Canon’s Dynamic IS 5-axis image stabilization.
Fast, precise focusing with face detection
Adjustable focusing speeds and advanced Hybrid AF system provide fast and precise focusing. Use the ultra-bright high-resolution 3.5-inch LCD display to set focus by touching the AF point on the screen. Face Detection AF and Face Tracking are available while Manual Focus is set via the focus/zoom ring.
XF-AVC and MP4 for flexible recording
Choose from XF-AVC or MP4 recording formats. Record XF-AVC 4K UHD 160Mbps at 30P and Full HD 45Mbps at 60P/60i/30P/24P. For smaller files, record MP4 in 4K 150Mbps at 30P/24P and Full HD 35Mbps or 17Mbps at 60P/30/24P.
Professional input and output
Output options include 3G-SDI, simultaneous backup and relay recording via dual SD cards and Infrared mode. Record Slow Motion in Full 5x HD or Fast Motion in 4K/Full HD up to 1200x. Colour match with other Canon cameras using the custom picture menu.
Main Unit Specs
Sensor |
1/2.3-inch 4K UHD CMOS sensor
|
Lens |
Zooming ratio, focal length (35 mm camera equivalent): 20x optical zoom, approx. 29.3 - 601mm (4K UHD IS off/standard IS on)/ approx. 30.5 - 627mm (Full HD IS off/standard IS on) Aperture: 8 blades Image Stabilizer: Optical + electronic correction
|
Infrared camera supported |
YES
|
Monitor |
3.5-inch (approx. 2.76 million dots), LCD, Capacitive touch panel
|
EVF |
0.36-inch (approx. 1.77 million dots), OLED, tiltable
|
Looks |
Standard
|
Movie Recording |
MXF: YES (XF-AFC) AVCHD: NO MP4: YES LPCM 4ch audio: YES (not available during 720 recording) Simultaneous Recording: Double recoriding OSD Recording: YES Slow and Fast (S&F) Motion Recording: YES Cinema-look filters: NO
|
Recording Media |
Built-in memory: NO Memory card: SD card (2 slots)
|
Professional use terminals |
SDI terminal: YES (3G-SDI) GENLOCK, TC: NO XLR terminal (INPUT 1, INPUT 2): YES
|
Other terminals |
HDMI, separate headphones, USB (USB Type-C), DC IN (USB Type-C), re-mote and MIC terminal (supports plug-in power)
|
Accessory shoe |
Handle unit: Cold shoe
|
Detachable handle |
YES (XLR terminal, built-in infrared light, mic holder, cold shoe, zoom lever, trigger, tally lamp)
|
Wi-Fi |
NO
|
GPS |
NO (Accessories supported)
|
Lens hood with barrier |
YES
|
Dimensions |
Approx. 4.3 x 3.3 x 7.2 in. / 109 x 84 x 182mm
|
Weight |
Body only: Approx. 1.65 lbs. / 750 g Lens hood, mic holder unit, handle unit, BP-820 and memory card (1 pc) included: Approx. 2.51 lbs. / 1140 g
|
